序号/Sr.No. | 项目/Item Name | 单位/Unit | 参数/Datas | 备注/ Remarks | |
1 | 公称容积流量/额定排气压力/F.A.D/Pressure | （m3/min）/ MPa | 4.5/0.8 | ||
2 | 环境温度/Ambient Temperature | ℃ | -5～+45 | ||
3 | 冷却方式/Cooling Mode | 风冷 | |||
4 | 排气温度/Discharge Temperature | ℃ | ≤环境温度+15 | ||
5 | 润滑油量/Oil Volume | L/kg | 16L | ||
6 | 传动方式/Driven Mode | 直联 | |||
7 | 气量调节方式/Adjusting way of air capacity | 变频调节 | |||
8 | 气体含油量/Oil Content in Discharge Air | ppm | ≤3 | ||
9 | 噪声/Noise | dB(A) | 72±2 | ||
10 | 润滑油牌号/Oil Brand | 开普 | |||
11 | 安全阀设定压力/Safety valve setting pressure | MPa | 额定工作压力x1.1 | ||
12 | 电动机/Motor
| 功率/Motor Power | kW | 30 | |
转速/Main Motor Nominal Rpm | rpm | 3900 | |||
起动方式/Starting Mode | 变频启动 | ||||
电压/频率Voltage/Frequency | V/Hz | 380/260 | |||
防护等级/绝缘等级Protection Class/Insulation Class | IP23/F | ||||
13 | 风机/Fan
| 功率/Fan Power | kW | 1.1 | |
电压/频率Voltage/Frequency | V/Hz | 380/50 | |||
转速/Main Fan Nominal Rpm | rpm | 1440 | |||
风量/Air Volume | m3/h | 7500 | |||
14 | 外形尺寸/Dimentions | mm | 1080x850x1200 | ||
15 | 重量/N.W | kg | 324 | ||
16 | 出口管径/Outlet Connection | in | Rp1 | ||
Unit Is Too Large For Liftgate Service, Shipping Dock Or Forklift Required
Hande screw air compressor Highly Efficient Gear-Driven Rotary Screw Compressor
Reliable gears eliminate belt changes and reduce transmission loss
Rated for 8,000 hours with premium synthetic lubrication; low oil carryover protects component
Infologic2 Basic Controller
Completely programmable auto-restart and remote start/stop
Convenient Display Panel
Includes auto run, general alarm and power-on LED's
Pressure display, temperature and dewpoint display
Motor start limit; max & min temperature default settings
100% Duty Cycle Motor
Wye-Delta reduced voltage start for industrial applications
Delivered in 460V-3; includes kit for 230V-3 wiring, must be installed by a licensed electrician
Operation
Full sound enclosure for extra low noise levels
Rotary screw technology provides a quiet solution and greatly reduces vibration
Increased Maintenance Simplicity
Fast and easy out of box installation
Hinged doors and detachable panels for quick access
Constant view fluid monitoring and spin-on fluid filter simplifies maintenance
Extended 3 Year Factory Warranty Available
True Blue 5-Year Warranty
Covers airend, motor, separator reservoir, cooler/heat exchanger
