Oil injected, 1:1 direct drive, fixed speed compressors, featuring an IE3 motor, fully programmable digital controller and 30% oversized cooler and separator.
1:1 Direct Drive Coupling
IE3 Premium Efficiency motor
Simple programmable controller
Schneider Control Gear
MCCB Protection with electrical Isolator up to 75kW
30% Oversized Separator & Cooler
Easy Access for servicing
Technical Parameters of HD-37 fixed speed air compressor
序号/Sr.No. | 项目/Item Name | 单位/Unit | 参数/Datas | 备注/Remarks | ||
1 | 公称容积流量/额定排气压力/F.A.D/Pressure | (m3/min)/ MPa | 6.2/0.8; 5.25/1.0; 5.0/1.2 | |||
2 | 环境温度/Ambient Temperature | ℃ | -5~+45 | |||
3 | 冷却方式/Cooling Mode | 风冷/Air Cooling | ||||
4 | 排气温度/Discharge Temperature | ℃ | ≤环境温度+15 /≤Ambient Temperatur+15 | |||
5 | 润滑油量/Oil Volume | L/kg | 18L | |||
6 | 传动方式/Driven Mode | 直联/Direct | ||||
7 | 气量调节方式/Adjusting way of air capacity | ON/OFF | ||||
8 | 气体含油量/Oil Content in Discharge Air | ppm | ≤3 | |||
9 | 噪声/Noise | dB(A) | 72±2 | |||
10 | 润滑油牌号/Oil Brand | 壳牌Shell,S46 | ||||
11 | 安全阀设定压力/Safety valve setting pressure | MPa | 额定工作压力x1.2 /Nominal Working Pressure x1.2 | |||
12 | 电动机/Motor
| 功率/Motor Power | kW | 37 | ||
转速/Main Motor Nominal Rpm | rpm | 2960 | ||||
起动方式/Starting Mode | Y-△启动/Star-delta Start | |||||
电压/频率Voltage/Frequency | V/Hz | 380/50 | ||||
防护等级/绝缘等级Protection Class/Insulation Class | IP23/F | |||||
13 | 风机/Fan
| 功率/Fan Power | kW | 1.1 | ||
电压/频率Voltage/Frequency | V/Hz | 380/50 | ||||
转速/ Main Fan Nominal Rpm | rpm | 1440 | ||||
风量/Air Volume | m3/h | 8000 | ||||
14 | 外形尺寸/Dimentions | mm | 1500x1000x1330 | |||
15 | 重量/N.W | kg | 660 | |||
16 | 出口管径/Outlet Connection | in | Rp1,1/2 | |||
