Product parameters

Power: The power of a from 5 horsepower (hp) to 350 hp.

Capacity: The capacity in cubic feet per minute (CFM) and ranges from 10 CFM to 1200 CFM.

Pressure: The pressure from 80 pounds per square inch (psi) to 150 psi.

Efficiency: The efficiency is measured in terms of the air delivery per unit of energy input, typically in CFM per horsepower (CFM/hp).

Motor speed: The typically ranges from 900 to 1800 revolutions per minute (RPM).

Cooling method: Single Stage Screw Air Compressors can be air-cooled or water-cooled.

Noise level: The noise level of a Single Stage Screw Air Compressor can range from 65 decibels (dB) to 85 dB.

Dimensions and weight: The dimensions and weight of a vary depending on the model and capacity.

Air Intake: The air intake process begins with the intake valve opening to allow atmospheric air to enter the compressor. The air is then filtered to remove any particulates or contaminants that could damage the compressor.

Compression: The air is then compressed by the screw rotor as it rotates. As the rotor turns, the air is forced through the compression chamber, where it is compressed to the desired pressure.

Cooling: The compressed air is then cooled to remove any heat generated during compression. This is typically achieved through an aftercooler or intercooler, which uses ambient air or a coolant to remove the heat.

Oil Separation: During compression, oil is injected into the compression chamber to lubricate and cool the compressor. The compressed air and oil mixture is then passed through an oil separator, which removes the oil from the air.

Air Storage: The compressed air is then stored in a receiver tank, where it can be used for various applications.

Automatic Drain: To prevent moisture buildup in the receiver tank, an automatic drain valve is typically installed to periodically remove any condensate that accumulates.

Control System: A control system is used to regulate the operation of the compressor, including the speed of the screw rotor, the pressure of the compressed air, and the temperature of the compressor.

Maintenance: Regular maintenance is required to ensure the compressor operates efficiently and reliably. This includes oil changes, filter replacements, and inspections of the compressor components.

Elastic direct-connect drivetrain

● Use imported brand elastic coupling for direct transmission, combining the motor and the air end into one, reliable operation and high transmission efficiency
