Product Introduction
Portable Screw Air Compressor has the advantages of high efficiency, low noise and smooth operation. It has strong pumping power and long service life. It has external silencer, which multiplies the effect of noise reduction, and it adopts high quality rubber foot pad with good cushioning effect. Portable Screw Air Compressor uses pure copper motor with small vibration. It uses a large-diameter cooling fan, which makes the heat dissipation more efficient and can extend the life of the motor well.
Advantages
1. It features fast heat dissipation and it can well prolong life.
2. Large-aperture cooling holes.
3. Reduce the rapid heat dissipation of the air compressor system to ensure that the system is not high temperature.
4. Five-in-one shock and noise reduction.
5. Portable Screw Air Compressor applies honeycomb excellent sound insulation cotton, which can greatly reduce noise.
| Model | HD-90 | ||
| Working pressure: | 8bar | 10bar | 12bar |
| Air Delivery (m³/min) | 15 | 13.8 | 12.3 |
| Air Delivery (CFM) | 530 | 488 | 435 |
| Motor power | 90KW/120HP | ||
| Power voltage: | 380V/50hz/3phase (different voltage is available) | ||
| Compressor type: | Fixed Speed Rotary Screw Air Compressor | ||
| Cooling Mode | Air cooling | ||
| Starting mode | Star-delta Start | ||
| Ambient temperature | -5℃ ~ +45℃ | ||
| Discharge temperature | ≤ Ambient temperature+15℃ | ||
| Dimension (mm) | 2000*1250*1670 | ||
| Product display： |
| Production Capability |
| Corporate Qualifications |
| Global exhibition & Training |
| Packing and delivery |
